Motorola MXM600 - Connection Plan for the Junction Box Accessory Plug; Figure 48: Connection Plan for the Speaker

3.6.4
Connection Plan for the Junction Box Accessory Plug
Figure 48: Connection Plan for the Speaker
10
9
8
7
6
5
4
3
2
1
2
1
2
1
Table 58: Associated Components
Number Description
1 Junction Box 10 Pin Accessory Plug
2 Speaker
