Motorola MXM600 - Figure 70: IP54 RECH

To Next Page

To Previous Page

Mobile Micro-

phone Port

(MPP) Pin

Default Functions Alternative

Functions

USB Functions RS232 Func-

tions

10 GPIO_0 GPIO_0 INPUT GP Input or

Output, PWR

GP Input or Out-

put, PWR ON

GP Input or Out-

put, PWR ON

NOTE: The connector enters one of the five modes automatically based on the automatic detection of

the connected accessory.

Figure 70: IP54 RECH – Rear Connectors

9 8 7 6 5 4 3 2 1

1 2 3 4 5 6 7 8 9 10 11 12 13

14 15 16 17 18 19 20 21 22 23 24 25

MN009998A01-AA

Chapter 4: Connectors and PIN Assignment

108

Motorola MXM600 - Figure 70: IP54 RECH - Rear Connectors
