Motorola MXM600 - Installing the Accessories Expansion Cable; Extra Accessories for the IP54 or IP67 Remote Ethernet Control Head, and Telephone Style Control Head

Number Description
2 Mobile Microphone Port (MMP)
3 Accessories Expansion Cable PMKN4429_/PMKN4456_ (IP67 RECH)
3.3.7
Installing the Accessories Expansion Cable
The following steps are applicable to both IP54 Remote Ethernet Control Head (RECH) and IP67 RECH.
Procedure:
1. Plug in the Accessories Expansion Cable to the DB25 Port of the RECH.
2. To secure the Accessories Expansion Cable in place, tighten the screws at the DB25 connector.
3. Mount the Mobile Microphone Port (MMP) or USB port module to a surface. To fix the module
securely, tighten the two screws on both sides of the module.
NOTE: For more information on the connector pin functions of the Accessories Expansion Cable
and the Mobile Microphone Port (MMP) or USB Port Module, see Accessories Expansion Cable
on page 112.
3.3.8
Extra Accessories for the IP54 or IP67 Remote Ethernet
Control Head, and Telephone Style Control Head
The Accessories Expansion Y-Cable (PMKN4133_ for IP54 Remote Ethernet Control Head (RECH), or
PMKN4333_ for IP67 RECH) allows you to connect extra accessories.
MN009998A01-AA
Chapter 3: Radio Installation
58
