Table 54: Mechanical Parts List for Installation
Item Description Part Number
1 IP67 RECH Ethernet Cable PMKN4320_ (3 m)
NOTE: Recommended for Motorcy-
cle Mount.
PMKN4321_ (5 m)
PMKN4322_ (7 m)
PMKN4323_ (10 m)
PMKN4324_ (15 m)
PMKN4325_ (40 m)
2 Motorcycle Remote Control
Head (TELCO) Cable
PMKN4030_
3 IP67 RECH Trunnion Kit PMLN5092_
3.5.3
Extra Connectivity to the IP67 Remote Ethernet Control
Head
For information on adding extra connectivity using the Accessories Expansion Cable and the Mobile
Microphone Port (MMP). See Installing the Accessories Expansion Cable on page 58.
3.6
Junction Box Installation
The data junction box (GMLN7825_) assists easy installation for dash and remote mount configurations.
The junction box allows you to add a laptop to the remote configuration. The junction box allows connections
of a visor microphone, various accessories, or fist microphone.
WARNING: The junction box (GMLN7825_) is only compatible with MXM600.
NOTE: Only trained personnel can install the mobile terminal. All installations must take place in
accordance with the requirements of the vehicle and antenna manufacturer or supplier.
MN009998A01-AA
Chapter 3: Radio Installation
76
