Motorola MXM600 - Remote Ethernet Control Head Y-Cable (Accessories Expansion Cable); Figure 79: Mobile to Mobile Ethernet Cable Pin Diagram; Figure 80: RECH Y-Cable Pin Diagram

Figure 79: Mobile to Mobile Ethernet Cable Pin Diagram
CONNECTION
BRICK 1
TX+
TX-
RX+
RX-
GND
GND
CH ON OFF OUT
CH ON OFF IN
P1
2
3
4
7
5
6
8
9
P2
4
7
2
3
5
6
9
8
COLOR
GREEN
GREEN / WHITE
BLUE
BLUE / WHITE
BLACK
BROWN
ORANGE
GRAY
DRAIN
BRICK 2
RX+
RX-
TX+
TX-
GND
GND
CH ON OFF IN
CH ON OFF OUT
SHIELD SHIELD
4.8.7
Remote Ethernet Control Head Y-Cable (Accessories
Expansion Cable)
Cable Part Number: PMKN4333_ (5A)
Figure 80: RECH Y-Cable Pin Diagram
MN009998A01-AA
Chapter 4: Connectors and PIN Assignment
117
