Figure 49: Connection Plan for the Emergency Switch
1
2
3
4
5
6
7
2
8
9
10
1
Table 59: Associated Components
Number Description
1 Junction Box 10 Pin Accessory Plug
2 Emergency Switch
MN009998A01-AA
Chapter 3: Radio Installation
82
