The keypad labeling of the control head varies according to the specific customer or country requirements.
See Table 12: Control Heads on page 22.
MXM600 is compatible with two types of Remote Control Heads:
Figure 38: Comparison of RECH Types
Table 51: Compatibility of IP67 Control Heads
Control Head Description
IP67 RECH Compatible with all MXM600 Single Remote Expansion
Head (SREH), Dual Remote Expansion Head (DREH),
and Databox Expansion Head (DEH). Only use Ethernet
IP67 remote cable. See Mechanical Parts List for IP67
Remote Mount Installation on page 75.
TELCO IP67 Control Head (Legacy) Only compatible with PMLN4904_. Only use TELCO ca-
bles. See Mechanical Parts List for IP67 Remote Mount
Installation on page 75.
MN009998A01-AA
Chapter 3: Radio Installation
71
