Item Description Part Number
3 Expansion Heads See Table 14: Expansion Head Kits on
page 25.
NOTE:
Pay attention to the effects of Electro Magnetic Compatibility (EMC) in vehicle installations. Also, over
long cable requires additional protection. Motorola Solutions has suitable suppression kits such as Part
Number 01015001001 Toroid EMC Suppression Kit.
Wind the Remote Mount Cable ten times around each toroid.
Place each toroid 30.0±2.5 cm respectively from the expansion head and the control head.
Winding at both ends reduces the effective cable length by approximately 0.8 m.
Fix the toroids firmly to a stable surface once the Remote Mount Cable is connected.
Dual Remote Expansion Head (DREH) Installation
This section explains the Dual Remote Mount installation - M3.
The Dual Remote Mount option provides the terminal with the option of an IP54 RECH, IP67 RECH, or
TSCH.
The following are the possible configurations:
● Remote Mount installation with IP54 RECH
● Remote Mount installation with IP67 RECH
● Remote Mount installation with TSCH
● Dual Control Head with two IP54 RECH
● Dual Control Head with two IP67 RECH
● Dual Control Head with two TSCH
● Dual Control Head with a combination of IP54 RECH and TSCH
● Dual Control Head with a combination of IP67 RECH and TSCH
● Dual Control Head with a combination of IP54 RECH and IP67 RECH
● Multi-Radio Control Installation with TSCH
● Multi-Radio Control installation with IP54 RECH
● Multi-Radio Control installation with IP67 RECH
IMPORTANT:
● The Ethernet cables shown in the following illustrations require three ferrite clamps (part number:
91012044001), with two turns of wire around them. Manually install the first ferrite clamp
approximately 60 cm away from the control head, and with a minimum spacing of 3 cm between the
next two ferrite clamps.
● Connect the control head to Port 1 of the Dual Remote Expansion Head.
MN009998A01-AA
Chapter 3: Radio Installation
45
