DCS Command System User’s Guide
Introduction To DCS
Recommended Wiring Method
11
Note: This very quick wiring scheme (through the Fixed In 1 and Fixed Out 1 inputs) allows for
operation of the connected loop of track in DCS command mode only. Please see the “Advanced
Connection” section of this manual in the “Universal Operation” chapter for all the wiring options if
you have more complex wiring and operational needs, including conventional mode and TMCC operation.
Maximum Power Input
0-22VAC,190VAC, 10AMP
OR
0-24VDC, 10AMP
