4 Handling the printer VJ-1624 OPERATION MANUAL
4-32
NOTE
• Make sure that spectrophotometer is NOT installed at an angle, and that there in no gap between
the connector and spectrophotometer.
10. Press the [Enter] key.
• "Wait for a while..." is displayed on the operation panel.
• The printer checks the connection between the printer and spectrophotometer.
• "Set white plate then close left maintenance cover." is displayed on the operation panel.
11. Remove the white reference plate from the plate installation place, turn it over so that the white side
faces up, and install it back to the original place.
No. Name
1 Spectrophotometer
2 Release buttons
3 Print head section
4 Connector
4
1
1
2
3
To Next Page
