VJ-1624 OPERATION MANUAL 4 Handling the printer
4-31
NOTE
• When a certain time has passed without opening the maintenance cover, the print head returns
toward the right side of the printer to protect the print head. "Attaching instrument [ENTER]"
is displayed. Restart from the Step 6.
8. Firmly pinch the tabs on both sides of the connector cap with your fingers, pull the connector cap
forward to remove it from the print head.
9. Press the release buttons on both sides of spectrophotometer (SPECTROVUE VM-10), install it to
the connector at the print head.
No. Name
1 Maintenance cover
No. Name
1 Connector cap
2Tabs
3 Print head section
1
1
1
2
2
3
