VJ-1624 OPERATION MANUAL 6 Maintenance
6-9
(3) Replacing steps
Follow the procedure below to replace the roll media.
1. If the printer is turned ON, confirm that operation such as printing is not in progress.
2. Raise the media loading lever.
3. Turn the flanges of the roll media holder and take up the roll media.
4. Loosen the fixing lever of the right roll media holder and remove the roll media from the roll media
holder.
No. Name
1 Media loading lever
No. Name
1 Roll media holder
2 Roll media
1
11 2
