6 Maintenance VJ-1624 OPERATION MANUAL
6-16
• Flushing-box sponge replacement is complete.
(3-b) Replacement procedure (on the opposite side of the origin side)
Follow the procedure below to replace the Flushing-box sponge on the opposite side of the origin side.
1. If the printer is turned ON, make sure the following.
• Printing or other operations are not in progress.
• The operation panel display is Normal.
2. Open the front cover.
3. Use tweezers to remove the flushing-box sponge from the flushing-box.
No. Name
1 Front cover
No. Name
1 Flushing boxes
2 Flushing-box sponges
1
1
1
2
To Next Page
