VJ-1624 OPERATION MANUAL 6 Maintenance

6-23

9. Close the maintenance cover.

10. Press the [Enter] key on the operation panel.

• The print head returns to its original position.

• "CR Maine.: Start" is displayed on the operation panel.

11. Press the [Menu] key on the operation panel.

No. Name

1 Maintenance cover
