2 Product overview VJ-1624 OPERATION MANUAL

2-10

NOTE

• For details on Status message, refer to "7.2.1 Status messages".

Normal

Setup Menu Display

[Menu] key

[Cancel] key

Leave the printer

as it is for 3 minutes
