VJ-1624 OPERATION MANUAL 6 Maintenance
6-39
7. When some foreign substance such as dust or ink clump is attached, use the cleaning stick to remove
it.
8. Close the left maintenance cover.
• Close the cover firmly until it is locked.
9. Press the [Enter] key on the operation panel.
No. Name
1 Around the print head
2 Head guide
3 Nozzles
4 Cleaning stick
No. Name
1 Maintenance cover
221
344
