3 Before using VJ-1624 OPERATION MANUAL
3-22
NOTE
• When there is remaining cleaning fluid pack and smart chip card, clarify the corresponding
pack and card, and store it as a set.
10. Install the ink pack and smart chip card to high capacity pack adapter.
11. Shake the high capacity pack adapter gently two to three times and insert it to the slot.
NOTE
• Do not insert the high capacity pack adapter into the ink cartridge slot without an ink pack
attached.
The remaining information of smart chip card will be overwritten and the ink pack will not be
usable.
• Insert the high capacity pack adapter all the way to the end of the slot.
• When a high capacity pack adapter is installed, "Ink Refill **%" is displayed on the operation
panel and ink replenishment starts.
• Initial filling takes about six minutes.
Ink filling operation and pause operation are repeated during the ink replenishment.
• When "100%" is displayed, the ink replenishment is complete.
No. Name
1 High capacity pack adapter
2 Ink cartridge slot K
3 Ink cartridge slot C
4 Ink cartridge slot M
5 Ink cartridge slot Y
1
5
4
3
2
To Next Page
