3 Before using VJ-1624 OPERATION MANUAL
3-28
3. Set the roll media to the roll media holder (Left).
4. Set the roll media to the roll media holder (Right) and fix the fixing lever.
5. Loosen the fixing levers of the right and left roll media holders, move the roll media to the center and
tighten the levers.
NOTE
• Fix the roll media holders by pressing the holders to the printer.
No. Name
1 Roll media holder (Left)
2 Roll media
No. Name
1 Roll media holder (Right)
2 Roll media
3 Fixing lever
1 2
1
3
2
