VJ-1624 OPERATION MANUAL 3 Before using

3-45

g. Press the [>] key on the operation panel.

• "Adj.Print1: Standard" is displayed on the operation panel.

h. Press the [+] key or [–] key to select "Adj.Print1: Standard>".

i. Press the [Enter] key on the operation panel.
