3 Before using VJ-1624 OPERATION MANUAL
3-48
3. Press the [Enter] key on the operation panel.
• The printer starts printing a rough adjustment pattern.
• The pattern images are printed on both paper edges and the center of the media.
4. Check the both ends and the center of the print result that printed with Adjust pattern, and select the
number from 1 to 11 that is not out of alignment.
• "4" is selected in the next printing sample.
NOTE
• "6" is the current setting value.
5. "Pattern *: 6" (* indicates a pattern name as shown below) is displayed on the operation panel.
• The pattern name (*) differs depending on the set print mode.
The print modes and their pattern names are as follows.
6. Press the [+] key or [–] key to enter the number that you selected in Step 4.
PrintMode PatternName
Quality 1, 2 C
Quality 3, 4 B
Graphics 1, 2 E
Graphics 3, 4 D
Banner 1, 2 A
Banner 3, 4 A
