3 Before using VJ-1624 OPERATION MANUAL
3-62
• An adjust print pattern for print quality adjustment is printed after warming up.
Six micro adjustment patterns will be printed. Input setting value for each pattern.
• Regarding adjust print patterns, the same patterns are printed repeatedly on both edges and the
center of the paper.
4. Check the both ends and the center of the print result that printed with Adjust pattern, and select the
number from 1 to 7 that is not out of alignment.
• "3" is selected in the next printing sample of "Micro Adjustment Pattern A".
• "5" is selected in the next printing sample of "Micro Adjustment Pattern B".
• "6" is selected in the next printing sample of "Micro Adjustment Pattern F".
NOTE
• "4" is the current setting value.
5. "PatternA: 4" is displayed on the operation panel.
6. Press the [+] key or [–] key to enter the number that you selected in Step 4.
