Oce PlotWave 360 User Manual

The media drawer
Illustration
1
2
3
5
4
Component - function table
#
Description / FunctionComponentNr
Carries the media rollroll holder1
Media placed on roll holder in first position.media roll 12
Media placed on roll holder in second position.
Note:
The scanner calibration sheet is located at
the back of roll 2.
media roll 2 (optional)3
Groove integrated behind the front cover of the
media drawer, on which the media can be easily
loaded.
roll loading station4
Button used to trim a strip of a new or damaged
media roll.
clean cut button5
Chapter 2 - Get to Know the Printing System32
The media drawer

Oce PlotWave 360 Specifications

General

Print Technology	Océ Radiant Fusing technology
Resolution	600 x 1200 dpi
Maximum Media Width	36 inches
Print Speed	6 A1/D prints per minute
Media Handling	2 rolls
Warm-up Time	Instant On
Weight	195 kg
Media Width	Up to 36 inches
