The components of the scanner (optional)
Note:
The scanner calibration sheet for the 'Océ Scanner Express' is located in the media
drawer , at the back of roll 2.
Illustration
1
4
3
2
5
[19] The integrated scanner.
The components of the scanner
#
Description / FunctionComponent
Closes off the scanner.scanner top cover1
Use the original feeding table to feed the
original into the scanner (face up).
original feeding table2
Use the scanner open levers to open the
scanner top cover.
scanner open levers3
Exit for the scanned original.originals exit4
Prevents that your output is not refed into
the scanner
Output refeed protector5
Chapter 2 - Get to Know the Printing System 37
The components of the scanner (optional)

Oce PlotWave 360 Specifications

General

Print Technology	Océ Radiant Fusing technology
Resolution	600 x 1200 dpi
Maximum Media Width	36 inches
Print Speed	6 A1/D prints per minute
Media Handling	2 rolls
Warm-up Time	Instant On
Weight	195 kg
Media Width	Up to 36 inches
