11-2 Suture Rack
Installation Procedure
1-, 2-, 3-Cell Color Touch Installation and Service Guide/67-2014 Rev G © 2011 Omnicell, Inc.
6 On Off Off On On On On Off
7 Off Off Off On On On On Off
8 On On On Off On On On Off
9 Off On On Off On On On Off
10 On Off On Off On On On Off
11 Off Off On Off On On On Off
12 On On Off Off On On On Off
13 Off On Off Off On On On Off
14 On Off Off Off On On On Off
15 Off Off Off Off On On On Off
16 On On On On Off On On Off
17 Off On On On Off On On Off
18 On Off On On Off On On Off
19 Off Off On On Off On On Off
20 On On Off On Off On On Off
21 Off On Off On Off On On Off
22 On Off Off On Off On On Off
23 Off Off Off On Off On On Off
24 On On On Off Off On On Off
25 Off On On Off Off On On Off
26 On Off On Off Off On On Off
27 Off Off On Off Off On On Off
28 On On Off Off Off On On Off
29 Off On Off Off Off On On Off
30 On Off Off Off Off On On Off
31 Off Off Off Off Off On On Off
32 On On On On On Off On Off
33 Off On On On On Off On Off
34 On Off On On On Off On Off
35 Off Off On On On Off On Off
36 On On Off On On Off On Off
37 Off On Off On On Off On Off
38 On Off Off On On Off On Off
39 Off Off Off On On Off On Off
40 On On On Off On Off On Off
41 Off On On Off On Off On Off
Table 11-1. Dip Switch Settings for Cabinet Zones
Zone
Switch
12345678
