© 2011 Omnicell, Inc. 1-, 2-, 3-Cell Color Touch Installation and Service Guide/67-2014 Rev G
Suture Rack 11-3
Installation Procedure
42 On Off On Off On Off On Off
43 Off Off On Off On Off On Off
44 On On Off Off On Off On Off
45 Off On Off Off On Off On Off
46 On Off Off Off On Off On Off
47 Off Off Off Off On Off On Off
48 On On On On Off Off On Off
49 Off On On On Off Off On Off
50 On Off On On Off Off On Off
51 Off Off On On Off Off On Off
52 On On Off On Off Off On Off
53 Off On Off On Off Off On Off
54 On Off Off On Off Off On Off
55 Off Off Off On Off Off On Off
56 On On On Off Off Off On Off
57 Off On On Off Off Off On Off
58 On Off On Off Off Off On Off
59 Off Off On Off Off Off On Off
60 On On Off Off Off Off On Off
61 Off On Off Off Off Off On Off
62 On Off Off Off Off Off On Off
63 Off Off Off Off Off Off On Off
64 On On On On On On Off Off
65 Off On On On On On Off Off
66 OnOffOnOnOnOnOffOff
67 Off Off On On On On Off Off
68 On On Off On On On Off Off
69 Off On Off On On On Off Off
70 On Off Off On On On Off Off
71 Off Off Off On On On Off Off
72 On On On Off On On Off Off
73 Off On On Off On On Off Off
74 On Off On Off On On Off Off
75 Off Off On Off On On Off Off
76 On On Off Off On On Off Off
77 Off On Off Off On On Off Off
Table 11-1. Dip Switch Settings for Cabinet Zones
Zone
Switch
12345678
