4-81
4-2 Function Mode
4
Functions
•You can select NO- or NC-contact input for each multi-function input terminal.
C001 to
C008
55 FOC : Preliminary excitation Preliminary excitation function 4-119
56 MI1 : Drive Programming input 1
Drive Programming input 1 to 8 
57 MI2 : Drive Programming input 2
58 MI3 : Drive Programming input 3
59 MI4 : Drive Programming input 4
60 MI5 : Drive Programming input 5
61 MI6 : Drive Programming input 6
62 MI7 : Drive Programming input 7
63 MI8 : Drive Programming input 8
65 AHD : Analog command held Analog command held 4-93
66 CP1 : Position command selection 1
Absolute position control mode
4-13967 CP2 : Position command selection 2
68 CP3 : Position command selection 3
69 ORL : Zero return limit signal

70 ORG : Zero return startup signal
71 FOT : Forward driving stop
4-142
72 ROT : Reverse driving stop
73 SPD : Speed/Position switching 4-140
74 PCNT: Pulse counter
Multi-function pulse counter 4-94
75 PCC : Pulse counter clear
82 PRG : Drive program start Drive program start 
no NO : No allocation 
Parameter
No.
Data Function name Reference item Page
Parameter
No.
Function name Data
Default
setting
Unit
C011 to
C018
Multi-function input 1 to
8 operation selection
00: NO
01: NC
• You can set NO- and NC-contact inputs
individually for multi-function input terminals 1 to 8
and the FW terminal.
• NO contact: "ON" with the contact closed, "OFF"
with the contact open.
• NC contact: "ON" with the contact open. "OFF"
with the contact closed.
• A terminal with reset (RS) setting function only can
be set as NO contact.
00 
C019
FW terminal operation
selection
00 
Related functions C001 to C008
