Omron 3G3RX - Holding Register Number List (2 Nd Setting); Holding Register Number List (Function Mode 2 Nd Setting)

4-216
4-4 Communication Function
4
Functions
* Data on H003 (Motor capacity selection) is the following code data.
<Holding Register Number List (2nd Setting)>
<Holding Register Number List (Function Mode 2nd Setting)>
16BCh
CANOpen communication
speed
P186R/W
00: Auto
01: 10Kbps
02: 20Kbps
03: 50Kbps
04: 125Kbps
05: 250Kbps
06: 500Kbps
07: 800Kbps
08: 1Mbps

16C0h CompoNet node address P190 R/W 0 to 63 
16C2h DeviceNet node address P192 R/W 0 to 63 
16C5h ML2 frame length P195 R/W
00: 32 bytes
01: 17 bytes

16C6h ML2 node address P196 R/W 21 to 3E 
Register
No.
Function name
Function
code
R/W Monitor and setting parameters
Resolu-
tion
Code data 00 01 02 03 04 05 06 07 08 09 10
Motor capacity (kW) 0.2  0.4  0.75  1.5 2.2  3.7 
Code data 11 12 13 14 15 16 17 18 19 20 21
Motor capacity (kW) 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Code data 22 23 24 25 26
Motor capacity (kW) 90 110 132 150 160
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
2103h
2nd acceleration time 1
F202
(HIGH)
R/W
0.01 to 3600.00 0.01 [s]
2104h
F202
(LOW)
R/W
2105h
2nd deceleration time 1
F203
(HIGH)
R/W
0.01 to 3600.00 0.01 [s]
2106h
F203
(LOW)
R/W
2107h
to
2202h
Not used  
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
2203h 2nd set base frequency A203 R/W 30 to 2nd Max. frequency 1 [Hz]
2204h 2nd maximum frequency A204 R/W 30 to 400 1 [Hz]
2205h
to
2215h
Not used  
