App-23
Appendix-1 Parameter List
Appendix
Others
b078
Integrated power
clear
[Clear kWh data]
Cleared with the Enter key after changing to
01
00 Yes
4-4
b079
Integrated power
display gain
[kWh display gain]
1 to 1000 1 No
b082
Starting frequency
[Start Frequency]
0.10 to 9.99 0.50 No Hz 4-68
b083
Carrier frequency
[Carrier frequency]
0.5 to 15.0 (0.4 to 55 kW)
*Derating enabled
5.0 No kHz
4-68
4-120
0.5 to 10.0 (75 to 132 kW)
*Derating enabled
3.0 No kHz
b084
Initialization selection
[Initialize Mode]
00: no (Clears the trip monitor)
01: Trip data (Initializes data)
02: Parameters )Clears the trip monitor and
initializes data)
03: Trip+Param (Clears the trip monitor and
parameters)
04: Trp+Prm+EzSQ (Clears trip monitor,
parameters and Drive program)
00 No
4-70
b085
Initialization
parameter selection
[Initial data select]
01
*Do not change.
01 No
b086
Frequency
conversion coefficient
[FQ scale factor]
0.1 to 99.9 1.0 Yes 4-2
b087
STOP key selection
[STOP key enable]
00: ON (Enabled)
01: OFF (Disabled)
02: Only RESET (Disabled only during stop)
00 No 4-70
b088
Free-run stop
selection
[Restart after FRS]
00: 0 Hz start
01: f-match (Frequency matching start)
02: Actv. f-match (Active Frequency Matching
restart)
00 No 4-71
b0
89
Automatic carrier
reduction
[Auto.Carrier reduce]
00: OFF (Disabled)
01: ON (Enabled)
00 No 4-73
b090
Usage rate of
regenerative braking
function
[BRD use ratio]
0.0 to 100.0 0.0 No % 4-74
b091
Stop selection
[Stop mode select]
00: Decel-Stop (Deceleration Stop)
01: Free-RUN (Free-run stop)
00 No 4-70
b092
Cooling fan control
[Cooling fan crtl]
00: Alws-ON (Always ON)
01: ON in RUN (ON during RUN)
01 No
4-74
b095
Regenerative braking
function operation
selection
[BRD ctrl select]
00: OFF (Disabled)
01: RUN-ON (Enabled (Disabled during
stop))
02: Alws-ON (Enabled (Enabled during stop))
00 No
b096
Regenerative braking
function ON level
[BRD activation]
330 to 380
660 to 760
360/
720
No V
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
