Omron NS User Manual

Section 5 Object Operations 5-8 Displaying and Searching Functional Object Lists
NS-Designer Operation Manual NS-Designer Operation Manual NS-Designer Operation Manual
Sorting Addresses in Descending Order
The addresses are sorted
alphabetically, so $B30 is
listed in this position.
Jumping to Functional Objects
The display can be changed (using the jump function) from the list to the position on the screen of a
specified object.
1. Click the number of the destination functional object to select the whole row.
Select the
destination
functional object.
2. Click the Jump Button or double-click the selected row.
The screen where the selected functional object is found will be displayed and the functional object
will flash because it is selected.
Note
♦ If Minimize when Jump is deselected (turned OFF) in the Functional Object List Window, the win-
dow will not be minimized when the jump function is used, but the destination functional object will
flash because it is selected.
N
N
o
o
t
t
e
e
5-44

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
