Section 2 Setup, Starting, and Exiting 2-4 Exiting the NS-Designer
NS-Designer Operation Manual NS-Designer Operation Manual
2-4 Exiting the NS-Designer
Use one of the following operations to exit the NS-Designer.
Select Exit from the File Menu. •
•
•
•
•
Click the Close Button at the top right of the Main Window.
Double-click the NS-Designer icon at the top left of the Main Window.
Click the NS-Designer icon at the top left of the Main Window and select Close from the Control
Menu Box.
Press the Alt + F4 Keys.
If the project data that is open has not been saved, a confirmation message will be displayed.
When the NS-Designer is exited, the system will return to the Windows screen.
2-15

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
