Section 10 Transferring Data 10-1 Transferring Data to the PT
NS-Designer Operation Manual
Reference
When uploading data, only the whole project can be transferred. Transferring
separate screens is not possible.
The contents of system setting on the NS-Designer cannot be uploaded.
R
R
e
e
f
f
e
e
r
r
e
e
n
n
c
c
e
e
10-1-4 Transferring Screen Data
Individual screen data stored in the selected project can be transferred to PT or Memory Card.
Procedure
1. Display the Screen Data Transfer Dialog Box
2. Select Select Project from the Mode Menu or right-click on the Screen Data Transfer Dialog Box
and select Select Project from the pop-up menu.
3. Click the Select Project Button and select the project. (The default selection is the project cur-
rently being edited by the NS-Designer. Normally, selecting the project is not required.)
Reference
♦
When transferring screen data that is being edited, save the screen data before
transferring. If the data is not saved before transferring, the most recently saved
data will be transferred and any unsaved changes will be lost in the transfer
data.
R
R
e
e
f
f
e
e
r
r
e
e
n
n
c
c
e
e
4. Click the Comms. Method Button and set the communications method. For details, refer to 10-1-2
Communications Settings for NS-Designer.
5. Click the Connect Button. The computer will be connected to the PT.
6. Select the screen data to transfer from the list box for the NS-Designer. Click the Select Update
Screen Button to automatically select only screen data with different modification dates between
the computer and PT or Memory Card.
10-23
