Section 10 Transferring Data 10-2 Transferring Data to and from a Memory Card
NS-Designer Operation Manual
10-2-2 Procedure for Transferring Data to a Memory Card in the PT
Use the following procedure to transfer data between a Memory Card inserted in the PT and the
NS-Designer (personal computer).
1. Click the Windows Start Button and select Programs - OMRON – CX-One - NS-Designer -
Memory Card Transfer.
2. The Memory Card Transfer Dialog Box will be displayed.
3
4
5
6
7
2
1
Number Item Contents
1 Connect Button Connects the computer to the PT.
2 Cancel Button Disconnects the computer from the PT.
3 Comms.Method Button Displays the Comms Method Dialog Box.
4
Displays the next-higher folder.
Deletes the files selected in the File List.
If the selected folder is empty, the folder will be deleted. If the selected folder is
not empty, an error message will appear and the folder will not be deleted.
Creates a new folder.
5 Look in: Displays where the file is placed.
“/” indicates the root folder in the Memory Card.
6 File List Displays the files and folders that are in the folder as a list.
Selecting, transferring, and deleting the files or folders can be performed.
7
Downloads the selected files or folders from the file list of NS-Designer to the
Memory Card inserted in PT.
Uploads the selected files or folders from the file list of the Memory Card to the
computer.
10-31
