Section 5 Object Operations 5-10 Batch Settings
NS-Designer Operation Manual NS-Designer Operation Manual NS-Designer Operation Manual
5-10 Batch Settings
Changes settings for the main properties of multiple functional objects of the same type from the func-
tional object list. Settings for the following properties can be changed as a batch.
Comments •
•
•
Labels
Addresses
Functional objects can also be added to or deleted from lists.
Functional Object Property Settings
Properties for each functional object can be set as a batch. This section describes how to change set-
tings using ON/OFF Button functional objects as an example.
1. Select the functional objects for which the properties are to be set together.
Drag
2. Select Settings – Change Settings at Once.
Reference
♦ The shortcut keys for changing functional object settings as a batch are the Ctrl + K Keys.
R
R
e
e
f
f
e
e
r
r
e
e
n
n
c
c
e
e
The Change Settings at Once Window will be displayed. The properties for the selected functional
object will be displayed in a list.
3. Double-click the cell for the property items to be set to enter input mode.
Input mode
5-49

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
