Section 1 Overview 1-4 Outline of Operational Flow
NS-Designer Operation Manual
1-4 Outline of Operational Flow
Screen data is created with the NS-Designer as follows:
Start NS-Designer.
Open screen.
Set project properties.
Set screen properties.
Register host.
Lay out objects.
Save screen data.
Save project.
Check
p
ro
j
ect b
y
p
rintin
g
data.
Check object operation with test tool.
Transfer data to PT.
Select in dialog box.
A screen is automatically opened
when a new project is created.
Otherwise screens are opened
with
File - Open Screen
Settings - System Setting
Settings - Project Properties
Settings - Screen Properties
Settings - Register Host
File - Save Screen
File - Save Project
File - Print
Tools - Test
File – Transfer Data
Select PT model.
Make system settings.
Note
♦ Start actual operation only after sufficiently checking the operation of the screen data and host pro-
gramming.
