Section 2 Setup, Starting, and Exiting 2-5 User Interface
NS-Designer Operation Manual NS-Designer Operation Manual
2-5 User Interface
2-5-1 Basic Screen Functions
The configuration and names and functions of the components in the NS-Designer operation screen
are described here.
Title ba
r
Menu bar
Toolbars
Screen being
created
Status bar
Title Bar
The title bar displays the application name, project name, and screen number.
Menu Bar
Separates the functions into related groups.
Each group name is displayed in the menu bar and the functions are displayed in pull-down menus
under each group name.
Toolbars
Standard Toolbar
This toolbar displays frequently used functions as icons.
Create
New
Screen
Save
Project
Open
Screen
Cut Paste Redo
Create
New
Project
Open
Project
About
NS-Designer
Save
Screen
Copy Undo
Zoom
2-16

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
