eration Manual
Appendix 6 Error Messages
The error messages displayed on the NS-Designer are listed in the following table along with probable
countermeasures (in alphabetical order).
Message Countermeasure
Address after replacement is not set. Correctly designate the start address after replacement
for replacement in the Replace Dialog Box.
Address input format is not correct. Input
address again using correct format and
applicable type (bit, word, etc).
Set the address using the correct format. The correct
address can be set by using the Address Set Dialog
Box.
Address is not set. Set an address in the Address Dialog Box.
Address is not set. Sets the communications address.
Address setting after replacement is not
correct.
Set the start address after replacement to a value
within the proper address range.
Address type of start address and end ad-
dress is not the same.
Set the same type of address for the start address and
the end address.
Address will exceed limit. Pasting aborted. Check the range of addresses that can be set and re-
peat the operation so that the address range is not
exceeded.
Background file error. Check to see if the background file (BMP or JPEG) is
corrupted.
BMP file of the compressed format is not
supported.
Use a BMP file that is not compressed.
Cannot be set because there are already
more than 160,000 Always log points.
NS5:
Cannot be set because there are already
more then 120,000 Always log points.
A maximum of 160,000 points can be set to be always
logged (120,000 points for the NS5). Change the log
timing in the Data Log Group Setting Dialog Box, re-
duce the number log points, or delete addresses until
there are 160,000 or fewer points.
Cannot be set because the logging holding
capacity has been exceeded for the num-
ber of always logging points.
A maximum of 50,000 points can be set to be always
logged. Reduce the number of points to be always
logged, i.e., change the logging periods or reduce the
number of logs in the Data Log Group Setting Dialog
Box.
Cannot create a frame inside a frame. Position the frame outside any other frames.
Cannot create any more frames. Do not use more than 10 frames on one screen.
Cannot create any more new screens. Create no more than 4,000 user screens in any one
project.
Cannot create any more screens. Create no more than 4,000 user screens in any one
project.
Cannot create any more. Create no more than 500 fields in any one data block.
Cannot Delete the screen file stored in NS
hardware.
The project in the PT may be set to read-only. Initialize
data using Screen data region format on the Data Ini-
tialization Tab Page under System Menu and transfer
the whole project.
Check the following items.
PT power supply.
Cable connection.
Is the PT started? (If it is not started, end the transfer
program and start the PT.)
Cannot establish connection with specified
communications method.
Make correct settings for unset items and connect
again.
Cannot find any project files in NS hard-
ware.
Resend the whole project.
To Next Page
