Omron NS User Manual

Section 5 Object Operations 5-4 Editing
NS-Designer Operation Manual NS-Designer Operation Manual NS-Designer Operation Manual
No. Setting Details
3 Range Set the unit number range when the search host is a Temperature Controller. The unit
number ranges that can be set are as follows:
E5AN/E5AR: 0 to 31
E5ZN: 0 to 15
3. Click the Replace Button. A replacement confirmation dialog box will be displayed.
Click the Yes Button.
4. A dialog box will be displayed when the replacement has been completed. Click the OK Button.
Reference
♦ The shortcut keys for replacing addresses are the Ctrl + H Keys.
♦ If Current Screen or Screens is selected for the range for address replacement, addresses set us-
ing the following menu items cannot be replaced.
Settings - Flicker Setting
Settings - Alarm - Event Setting
Settings - Data Log Setting
Settings - Data Block Setting
Settings - System Setting
Settings - Project Properties - Macro
Settings - Screen Properties - Macro
♦ The addresses set in Internal Memory (Bit Memory and Word Memory) cannot be replaced.
R
R
e
e
f
f
e
e
r
r
e
e
n
n
c
c
e
e
5-4-9 Select All
Useful for selecting all objects or the same type of objects on a screen.
All Functional Objects/Fixed Objects
Selects all objects on the screen.
Select Edit - Select All - All Functional Objects - Fixed Objects.
Reference
♦ The shortcut keys for selecting all functional and fixed objects are the Ctrl + A Keys.
R
R
e
e
f
f
e
e
r
r
e
e
n
n
c
c
e
e
5-22

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
