Section 3 Manipulating Project Files 3-5 Saving a Project Under a Different Name
NS-Designer Operation Manual
3-5 Saving a Project Under a Different Name
1. Select File - Save Project As.
2. The Save Project As Dialog Box will be displayed.
Specify the directory and file name where the project will be saved, and click the Save Button.
Always observe the following precautions when specifying the project name.
•
•
The project name must be no more than 42 characters including the IPP extension.
Select a name using alphanumerics, underscore (_), dollar symbols ($), and periods (.).
If the project name is specified using other characters, symbols, or marks, an error will occur when
data is transferred to the PT.
Reference
♦ When the project name is changed and saved, all the original project data will also be copied to the
new project directory.
♦ When specifying the project name, if the specified save destination has an existing project, the ex-
isting project’s data will be deleted and overwritten with the currently open project data.
R
R
e
e
f
f
e
e
r
r
e
e
n
n
c
c
e
e
3-7

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
