Omron NS User Manual

Section 5 Object Operations 5-10 Batch Settings
NS-Designer Operation Manual NS-Designer Operation Manual NS-Designer Operation Manual
1
2
No. Setting Details
1 No. of Repetitions Sets the number of repetitions.
2 Replace Replaces existing data with the repeat string.
Replace Number in
Character String
If Replace Number in Character String is selected (turned ON), the numeric
value in the character string is incremented and the string is copied.
String Type
Select Character to replace numeric values in comment or label strings. Select
Address to replace numbers in addresses.
Example: Character – Button 1, Button 2, Button 3,…
Address
− $B0, $B1, $B2,….
Offset Specifies the offset value to be added to the numeric value being replaced.
3. Make the settings and then click the Repeat Button.
5-54

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
