Omron NS User Manual

Section 10 Transferring Data 10-3 Data Transfer Using SPMA
NS-Designer Operation Manual
PLC series CPU Unit Lot number
CJ1H-CPU65H
CJ1H-CPU66 H
CJ1G-CPU42 H
CJ1G-CPU43 H
CJ1G-CPU44 H
CJ1G-CPU45 H
CJ1M-CPU11
CJ1M-CPU12
CJ1M-CPU13
CJ1M-CPU21
CJ1M-CPU22
CJ Series
CJ1M-CPU23
CS1H-CPU63H
CS1H-CPU64 H
CS1H-CPU65 H
CS1H-CPU66 H
CS1H-CPU67 H
CS1G-CPU42 H
CS1G-CPU43 H
CS1G-CPU44 H
CS1G-CPU45 H
CS1D-CPU42S
CS1D-CPU44S
CS1D-CPU65S
CS Series
CS1D-CPU67S
030201 and later
Reference
♦
To send screen data to a PT through a PLC that is connected with a PT by a Serial network, the PT
must be connected to the built-in RS-232C port or peripheral port on the PLC’s CPU Unit. The screen
data cannot be transferred to a PT connected with the RS-232C port on a Serial Communications
Board or a RS-422A/485 port of the PLC.
♦
When connecting the PLC and PT by a Serial network (1:N NT Links), set NT Link Max on the Settings
– Host Link Port Tab Page in the CX-Programmer to a value greater than 1.
♦
Before transferring screen data from the NS-Designer to a PT that is connected by a Serial network
(1:N NT Links) through the PLC, confirm that High Speed is ON under Option – Pass Through PLC
Settings of the Screen Data Transfer tool.
R
R
e
e
f
f
e
e
r
r
e
e
n
n
c
c
e
e
10-35

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
