Section 11 Printing 11-2 Printing Page Information
NS-Designer Operation Manual NS-Designer Operation Manual NS-Designer Operation Manual
Reference
♦ All property information for objects will be printed for property settings. This may result in a large
number of pages being printed.
It is recommended that the Functional Object List is used to more efficiently check object settings.
The Functional Object List can be saved to a CSV file, which can also be printed.
Select Tools - Functional Object List, select the desired range, and click the Save Button to save
the Functional Object List to a CSV file. Refer to 5-9 Listing Functional Objects Used for details on
operating procedures.
♦ With data block tables, only the settings for each tab page in the Property Settings Dialog Box are
printed. Settings for each data block field (e.g., communications addresses, data formats, keypads)
are not printed.
R
R
e
e
f
f
e
e
r
r
e
e
n
n
c
c
e
e
11-7

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
