Appendices Appendix 8 Details of CLK Status
A-30
N
S
-
Desi
g
ner O
p
eration Manual
Address
(start address = n)
Bit Status Contents
0 Node 17
1 Node 18
2 Node 19
3 Node 20
4 Node 21
5 Node 22
6 Node 23
7 Node 24
8 Node 25
9 Node 26
10 Node 27
11 Node 28
12 Node 29
13 Node 30
14 Node 31
n + 24
15
Data Link Normal Operation
Status
Node 32
0 Node 1
1 Node 2
2 Node 3
3 Node 4
4 Node 5
5 Node 6
6 Node 7
7 Node 8
8 Node 9
9 Node 10
10 Node 11
11 Node 12
12 Node 13
13 Node 14
14 Node 15
n + 25
15
Data Link Error Detection
Status
Node 16
0 Node 17
1 Node 18
2 Node 19
3 Node 20
4 Node 21
5 Node 22
6 Node 23
7 Node 24
8 Node 25
9 Node 26
10 Node 27
11 Node 28
12 Node 29
13 Node 30
14 Node 31
n + 26
15
Data Link Error Detection
Status
Node 32

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
