Omron NS User Manual

Revision History
A manual revision code appears as a suffix to the catalog number on the cover of the manual.
Cat. No. V074-E1-07
Revision code
The following table outlines the changes made to the manual during each revision. Page numbers refer
to the previous version.
Revision code Date Revised content
01 May 2002 Original production
02 January 2003
Addition of data transfer passing through the networks
Addition of Switch Box function
Contents revised to reflect the upgrade from version 2.0 to
version 3.0
03 April 2003
Addition of information related to the printing function
Addition of information related to “V1” models
Addition of information related to other version upgrades
04 October 2003
Addition of information related to NS-Designer Ver. 5.0 up-
grade.
Addition of information related to NS5 PTs.
05 July 2004
Addition of information related to NS-Designer Ver. 6.0 up-
grade.
06 February 2005 Addition of information related to the NS5-V2 Series.
Addition of information related to other version upgrades.
07 October 2005
Notice: Information on general precautions notation and
copyright added before page P-1.
Read and Understand this Manual: Information on liabil-
ity and warranty added after P-3.

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
