Section 3 Manipulating Project Files 3-10 Changing the PT Model
NS-Designer Operation Manual
When the PT model is changed, the screen size will change as follows:
Model before
changing
Model after
changing
Screen size conversion
NS10
NS8
Converts the basic screen size to 640 × 480 dots.
Pop-up screens that are larger than 640 × 480 dots are converted to 640 ×
480 dots.
NS5-SQ/TQ
NS12
NS5-MQ
Converts the basic screen size to 320 × 240 dots.
Pop-up screens that are larger than 320 × 240 dots are converted to 320 ×
240 dots.
NS12
Converts the basic screen size to 800 × 600 dots.
NS8 No conversion.
NS5-SQ/TQ
NS10
NS5-MQ
Converts the basic screen size to 320 × 240 dots.
Pop-up screens that are larger than 320 × 240 dots are converted to 320 ×
240 dots.
NS12
Converts the basic screen size to 800 × 600 dots.
NS10 No conversion.
NS5-SQ/TQ
NS8
NS5-MQ
Converts the basic screen size to 320 × 240 dots.
Pop-up screens that are larger than 320 × 240 dots are converted to 320 ×
240 dots.
NS12
Converts the basic screen size to 800 × 600 dots.
NS10
NS5-SQ/TQ
NS8
Converts the basic screen size to 640 × 480 dots.
NS12
Converts the basic screen size to 800 × 600 dots.
NS10
NS5-MQ
NS8
Converts the basic screen size to 640 × 480 dots.
Reference
♦
When the model has been changed from the NS12, NS10, or NS5 to the NS8 (or, conversely, from
the NS8 to the NS12, NS10, or NS5), the size of the intervals in the touch-sensitive mesh are dif-
ferent, so it may not be possible to press some of the functional objects. After conversion, always
check that the functional objects are above the touch-sensitive mesh size by running validation from
the Tools Menu. Refer to Section 9 Validation for details on the validation function.
♦
Although screen data for the NS5-MQ0@-V2 is displayed in monochrome/16 grayscale levels on the
NS-Designer displays and the NS5-MQ0@-V2 screen, the data will be displayed in color if it is
converted to data for a PT model with color displays on the NS-Designer or transferred to a PT with
a color display screen. The color codes that are used when creating the screen data for the
NS5-MQ0@-V2 will be displayed for screen data and the image colors will be used for BMP and
JPEG data.
♦
All screen data created for PTs with color displays will be displayed in monochrome/16 grayscale
levels if the screen data is converted for the NS5-MQ0@-V2 on the NS-Designer or it is transferred
to the NS5-MQ0@-V2.
R
R
e
e
f
f
e
e
r
r
e
e
n
n
c
c
e
e
3-22

Omron NS Specifications

General

Power Supply	24 VDC
Display Size	5.7 to 12.1 inches (depending on the model)
Resolution	320 x 240 to 800 x 600
Touchscreen Type	Resistive
Display Type	TFT LCD
Communication Interfaces	RS-232C, RS-422/485, Ethernet, USB
Memory	Flash memory
Operating Temperature	0 to 50°C (depending on the model)
Storage Temperature	-20°C to 60°C
Protection Rating	IP65 (front panel)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
CPU	Proprietary Omron CPU (performance varies depending on the model)
