l
Host Name
Setting Description Default
Host Name Set the host name for the local Unit. The local host name can be
set for each Unit. The set host name is set to sysName of the
system group and lldpLocSysName of the lldp group in the MIB
(Management Information Base).
*1*2
(Single-byte alphanumeric characters, dots, and hyphens: 63
characters max.)
None
*3
*1. Since the local host name identifies the Unit, set the name so that it does not use the same name in the
same network.
*2. Refer to 11-1-4 MIB Specifications on page 1
1-4 for details on the MIB.
*3. If you do not set the local host name, the model of the Unit will be the local host name.
l
DNS
Setting Description Default
Use/
Do not use DNS
When you specify a host name for SNMP function, select the
Use Option if you use DNS for resolving host name.
A DNS server is required to use DNS.
Do not use
Priority DNS server
*1
Set the IP address of the DNS server.
Y
ou can set priority and secondary IP addresses.
None
Secondary DNS server None
Domain name
*1
Set the domain name of the domain to which the EtherNet/IP
port belongs.
(Single-byte alphanumeric characters, dots, and hyphens: 48
characters max.)
None
*1. These settings are required if you select the Use Option for DNS.
l
Host Name - IP Address
Setting Description Default
Host Name Addresses are converted according to this setting when a host
name is used to specify remote communications nodes.
Host names can be set whether DNS is used or not.
You can set up to six host names.
(Single-byte alphanumeric characters, dots, and hyphens: 200
characters max. with up to 63 single-byte alphanumeric charac-
ters between dots.)
None
IP Address Set the IP address of the registered host name. None
7 Sysmac Studio Settings for the EtherNet/IP Port
7-4
NX-series EtherNet/IP Unit User's Manual (W627)
