Setting Description Default
Port Number
Set the port number used for communications.
*3
Setting range: 1 to 65,535
None
*1. To use this function, select the Use Option for IP Forward in the port forward. If the Do not use Option
is selected, the sent frames will be discarded.
*2. On the client side of the external device, specify the IP address of the EtherNet/IP port on the NX-series
EtherNet/IP Unit and send the frame.
*3. Specify a port number that is not used by the NX-series EtherNet/IP Units. Refer to A-7 TCP/UDP Port
Numbers Used for the NX-series EtherNet/IP Unit
on page A-55 for details on the TCP/UDP port num-
bers that are used by the NX-series EtherNet/IP Units.
The following shows the applications that are not supported by the NX-series EtherNet/IP Unit, and
they are classified by whether this function is valid or invalid. The invalid applications cannot ac-
cess the CPU Unit even if the Protocol or Port Number are set.
Valid/Invalid Application
Valid Socket communications, secure socket communications, FTP server, MQTT communications
Invalid FTP client, NTP client, FINS/UDP, FINS/TCP, DB connection service, Modbus/TCP commu-
nications, DHCP client, OPC UA, SECS/GEM connection service, Robot integrated
l
Packet Filter
For information on usage and restrictions of Packet Filter, refer to 8-4 Packet Filter
on page 8-15.
Setting Description Default
Packet Filter Select whether to use Packet Filter or not.
Use
Do not use
Do not use
Source Set the conditions for the source. ---
IP Address Specifi-
cation Method
Select the method for specifying the IP address of the source.
any
*1
IP address specification
any
IP Address If the IP address specification method is IP address specification, set
the source IP address.
*2
None
Mask If the IP address specification method is IP address specification, set
the mask of source IP address.
*3
None
Destination Set the conditions for the destination. ---
IP Address Specifi-
cation Method
Same as those for the source.
IP Address
Mask
Protocol Set the communications protocol.
any
*4
tcp
udp
igmp
*5
icmp
*6
any
Source Port If tcp or udp is selected for Protocol, set the source port conditions. ---
7 Sysmac Studio Settings for the EtherNet/IP Port
7-7
NX-series EtherNet/IP Unit User's Manual (W627)
7-1 TCP/IP Settings Display
7
