Omron NX Series User Manual

CPU Unit Network Configura-
tor
hardware list name
Specifying
with network
variable
Specifying
with I/O memo-
ry address
EtherNet/IP Unit
NX-series CPU Unit ---- NX701
Yes
No
NX502
Yes
Yes
*1
NX102
Yes
Yes
*1
*2
NX1P2££££ Y
es
Yes
*1
*2
NX-EIP201
NX-EIP201
Yes
Yes
*1
*2
NJ-series CPU Unit
---
NJ501-££££
NJ301-££££
NJ101
Yes
Yes
*1
CJ1W-EIP21 CJ1W-EIP21 (NJ)
Yes
Yes
*1
CJ2H-CPU6£-EIP
--- CJ2B-EIP21
Yes Yes
CJ1W-EIP21 CJ1W-EIP21 (CJ2)
Yes Yes
CJ2H-CPU6£
CJ1W-EIP21 CJ1W-EIP21 (CJ2) No
Yes
CJ2M-CPU3£
--- CJ2M-EIP21
Yes Yes
CJ1W-EIP21 CJ1W-EIP21 (CJ2)
Yes Yes
CJ2M-CPU1£
CJ1W-EIP21 CJ1W-EIP21 (CJ2) No
Yes
CJ1 CPU Unit CJ1W-EIP21 CJ1W-EIP21 No
Yes
CS1 CPU Unit CS1W-EIP21 CS1W-EIP21 No
Yes
*1. To specify an I/O memory address for tag assignment, do not specify the address directly. Instead, cre-
ate a variable with an AT specification of the I/O memory address on the Sysmac Studio, and then speci-
fy the variable for the tag.
*2.
For NX102 and NX1P2 CPU Units, you need to set memory used for CJ-series Unit to use the I/O mem-
ory address. For details on memory settings used for CJ-series Unit, refer to the NJ/NX-series CPU Unit
Software User’s Manual (Cat. No. W501).
9 Tag Data Link Functions
9-81
NX-series EtherNet/IP Unit User's Manual (W627)
9-4 Tag Data Links with Other Models
9

Omron NX Series Specifications

General

Programming Languages	Ladder, Structured Text, Function Block Diagram, Sequential Function Chart
Communication Ports	Ethernet, USB, RS-232C, RS-485
Memory Capacity	Varies by model
Program Memory	Varies by model
Data Memory	Varies by model
Operating Temperature	0°C to 55°C
Power Supply	24 VDC
Ethernet Ports	1 or 2 ports (depending on model)
USB Ports	1 or 2 ports (depending on model)
Dimensions	Varies by model
Weight	Varies by model
