Event name Basic Ethernet Setting Error Event code 36010000 hex
Meaning An Ethernet setting error was detected.
Source X Bus Ethernet Function Module Source details 1 to 4: Mounting
position of the X
Bus Unit (unit
number)
and
communications
port 1/
communications
port 2
are given
in combination
Detection tim-
ing
At power ON or
Controller reset
Error attributes Level Minor fault Recovery Automatic re-
covery, cycle
the power sup-
ply
, or Controller
reset
Log category System
Effects User program Continues. Operation Ethernet communications are not possible for the rele-
vant communications port.
Indicators Ethernet NET RUN Ethernet NET ERR Ethernet LINK/ACT
OFF Flashes at 1-s intervals. ---
Device variable Variable Data type Name
ETN_Port1Status.EtnCfgErr BOOL Port1 Basic Ethernet Setting Error
ETN_Port2Status.EtnCfgErr BOOL Port2 Basic Ethernet Setting Error
Cause and cor-
rection
Assumed cause Correction Prevention
Parameter error Identify the cause of the error from
the attached information, correct
the settings, and then download
the settings again.
None
Power interruption while download-
ing Ethernet port settings
Please clear all memory or down-
load the settings.
Do not turn OFF the power supply
to the Controller while downloading
the Ethernet port settings.
Memory error If the above measures do not work,
replace the Unit.
None
Attached infor-
mation
Attached information 1: Error type
01 hex: Non-volatile Memory Access Error
, 02 hex: There is an inconsistency in the set values.
Attached information 2: Error Details
00 hex: Non-volatile memory access error
, 11 hex: Invalid communications speed setting, 12 hex: Unsupported
communications speed
Precautions/
Remarks
None
14 Troubleshooting
14-18
NX-series EtherNet/IP Unit User's Manual (W627)
