Event name IP Address Setting Error Event code 36020000 hex
Meaning An IP address setting error was detected.
Source X Bus Ethernet Function Module Source details 1 to 4: Mounting
position of the X
Bus Unit (unit
number)
and
communications
port 1/
communications
port 2
are given
in combination
Detection tim-
ing
At power ON or
Controller reset
Error attributes Level Minor fault Recovery Automatic re-
covery (after
downloading the
settings), cycle
the power sup-
ply, or Controller
reset
Log category System
Effects User program Continues. Operation Ethernet communications are not possible for the rele-
vant communications port.
Indicators
Ethernet NET RUN Ethernet NET ERR Ethernet LINK/ACT
OFF Flashes at 1-s intervals. ---
Device variable Variable Data type Name
ETN_Port1Status.IPAdrCfgErr BOOL Port1 IP Address Setting Error
ETN_Port2Status.IPAdrCfgErr BOOL Port2 IP Address Setting Error
Cause and cor-
rection
Assumed cause Correction Prevention
Parameter error Identify the cause of the error from
the attached information, correct
the settings, and then download
the settings again.
None
Power interruption while download-
ing Ethernet port settings
Clear all memory or download the
settings again.
Do not turn OFF the power supply
to the Controller while downloading
the Ethernet port settings.
The IP address obtained from the
BOOTP server is invalid.
Correct the IP address setting pro-
vided by the BOOTP server to this
port within the range specified for
the NX-series Controller
.
Set the IP address provided by the
BOOTP server to this port within
the range specified for the NX-ser-
ies Controller.
Memory error If the above measures do not work,
replace the Unit.
None
Attached infor-
mation
Attached information 1: Error type
01 hex: Non-volatile Memory Access Error, 02 hex: There is an inconsistency in the set values.
Attached information 2: Error Details
00 hex: Non-volatile memory access error
If there is an inconsistency in the set values:
1
1 hex: Illegal IP address, 12 hex: Illegal subnet mask, 13 hex: Invalid default gateway, 14 hex: Preferred DNS
setting error, 15 hex: Alternate DNS setting error, 16 hex: Illegal domain name, 17 hex: Illegal X Bus network
address
Precautions/
Remarks
None
14 Troubleshooting
14-19
NX-series EtherNet/IP Unit User's Manual (W627)
14-4 Checking with the Sysmac Studio, an HMI, and Instructions That Read Error
Status
14
14-4-4 Error Details
