Event name IP Router Table Setting Error Event code 36030000 hex
Meaning An error was detected in the IP routing function settings.
Source X Bus Ethernet Function Module Source details 1 to 4: Mounting
position of the X
Bus Unit (unit
number)
and
communications
port
are given in
combination
Detection tim-
ing
At power ON or
Controller reset
Error attributes Level Minor fault Recovery Automatic re-
covery (after
downloading the
settings), cycle
the power sup-
ply, or Controller
reset
Log category System
Effects User program Continues. Operation Communications that use the relevant IP routing set-
tings are not possible.
Indicators
Ethernet NET RUN Ethernet NET ERR Ethernet LINK/ACT
--- Flashes at 1-s intervals. ---
Device variable Variable Data type Name
ETN_IPRTblErr BOOL IP Router Table Setting Error
Cause and cor-
rection
Assumed cause Correction Prevention
Parameter error Identify the cause of the error from
the attached information, correct
the settings, and then download
the settings again.
None
Power interruption while download-
ing EtherNet/IP port settings
Clear all memory or download the
settings again.
Do not turn OFF the power supply
to the Controller while downloading
the EtherNet/IP port settings.
Memory error If the above measures do not work,
replace the Unit.
None
Attached infor-
mation
Attached information 1: Error type
01 hex: Non-volatile Memory Access Error
, 02 hex: There is an inconsistency in the set values.
Attached information 2: Error Details
00 hex: Non-volatile memory access error
If there is an inconsistency in the set values:
1
1 hex: Illegal IP router table settings, 12 hex: Illegal hosts settings, 13 hex: Invalid default gateway, 14 hex:
Illegal IP Forward settings, 15 hex: Illegal NAT settings, 16 hex: Illegal Packet Filter settings, 17 hex: Illegal
TCP/UDP Port Transfer settings
Precautions/
Remarks
None
14 Troubleshooting
14-20
NX-series EtherNet/IP Unit User's Manual (W627)
